1320mm Width Ed Copper Foil Shielding Rf Cage Shielded Room
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Red Copper Foil | RA Copper Foil Thickness | 0.1 0.15mm 0.2mm |
|---|---|---|---|
| Shielded Frequency | >100db In Band 10MHz-130MHz | Purity | 99.85% |
| Delivery Time | 5-8working Days | Color | Copper |
| RA Copper Foil Width | 300mm,600mm | Minimum Order Quantity | 500kg |
| Usage | MRI Room,Shielding EMI,electromagnetic Shielding,Conductive Shielding | ||
| Highlight | 1320mm width copper foil shielding,ed copper foil shielding,shielded room copper foil roll |
||
Product Description
600mm Width Ra Copper Foil Shielding Rf Cage Shielded Room
Description:
Electrodeposited (ED) copper foil is manufactured by depositing copper ions, via electrolysis,
onto a rotating metallic mandrel to form a thin layer of foil.
Through this process, very wide and high purity thin foils can be manufactured that are suitable for a range of applications from PCB’s to Lithium ion batteries.
| Item | Unit | Condition | Specification value | Inspection frequencies | Test method | |||
| 8 um | 10 um | 12 um | 18 um | |||||
| Purity | % | A | ≥ 99.9 | C | IPC-TM-650-2.3.15 | |||
| Area weight | g/㎡ | A | 72±4 | 89±5 | 107±5 | 155±8 | А | IPC-TM-650-2.2.12 |
| Drum Side Roughness (Ra) | um | A | ≤ 0.4 | А | IPC-TM-650-2.2.17 | |||
| Electrolyte Side Roughness(Rz) | um | A | ≤ 3.5 | А | IPC-TM-650-2.2.17 | |||
| Tensile strength | kg/mm2 | A | ≥ 35 | А | IPC-TM-650-2.4.18 | |||
| Elongation | % | A | ≥ 3 | ≥ 4 | А | IPC-TM-650-2.4.18 | ||
Application Of copper foil
Copper is great material of shielded signal .
Widely used for rf cage /MRI room installations,building roof to protect out of oxidizition .
There are two main installation ways of RF cage building .
First option :
ED copper foil 1320mm -basic step- Make Wooden Panel +Put copper foil Covered wooden frame +assemle copper foil wooden panel together.
Finished RF shielded cage as below:
Second option :
RA copper foil 600mm- basic step -Make bending edges of copper sheet +Fix sheets on wood walls +welding edges of 2 pcs sheets together.
Finished RF shielded cage as below:
Q1. Can I have a sample order for Ed Copper foil ?
A: Yes, we welcome sample order to test and check quality. Free A4 ED copper foil sample .
Q2. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. Airline and sea shipping also optional.
Q3. Do you have any MOQ limit ?
A: Low MOQ, 200kg for ED copper foil 1320mm ,500kg for RA copper foil 600mm
