3oz Conductive Shielding Tape 1320mm Wider Electrodeposited

  • 3oz Conductive Shielding Tape 1320mm Wider Electrodeposited
  • 3oz Conductive Shielding Tape 1320mm Wider Electrodeposited
Place of Origin China
Brand Name Jovi
Certification SGS
Model Number 1-CF-1
Minimum Order Quantity 200kg
Price USD 19-25 + kg
Packaging Details Wooden Case
Delivery Time 5-8 work days
Payment Terms Western Union, L/C, D/A
Supply Ability 20MT per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Thickness 3oz 0.105mm Width 1320mm
Packing Wooden Case MOQ 200kg
Material Red Copper Delivery Time 7 Working Days
Highlight

3oz conductive shielding tape

,

1320mm wide conductive shielding tape

,

copper foil tape with conductive adhesive
Leave a Message
Product Description

3oz 1320mm Wider Electrodeposited Conductive Copper Foil Shielding



Quick Detail:



1. 3oz 0.105mm thickness 1320mm width

2. MOQ 200kg

3. In roll shape and in wooden case

4. High Elongation and high tensile performance

5. Using for MRI RF Room or Faraday Cage Shielding Field



Description:



1. Lightweight



2. Copper Serves as an eddy current shield for EMI Protection.



3. Copper with 1320mm width or wider, can be more easy to install, especially for roofing, wall and floor.



4. Reinforced wall design



5. Easily and quickly modified on site



6. High performance, vertically-supported modular enclosure



7. Necessary to prevent RF noise from entering into the MRI scanner and distorting the image. Copper is

generally considered the best shielding for MRI rooms compared with Al and GL..



8. Copper is durable, has superior electrical conductivity and is extremely corrosion resistant. Copper is

also easily formed meaning that the shapes of the shield can be easily modified to suit rooms of different

shapes and sizes





Application:



Copper foil can be well used in MRI RF Room Shielding Installation and Faraday Cage.



Specification:





Quality Items General Technical Terms
Normal Thickness 2oz 3oz 4oz 5oz 6oz
0.07mm 0.105mm 0.140mm 0.175mm 0.210mm
Area Weight(g/m2) 560-610 838-960 1100-1280 1380-1600 1650-1920
Tensile Strength Room Temperature ≥28 ≥28 ≥28 ≥28 ≥28
(kg/mm2)
Elongation Room Temperature ≥10 ≥10 ≥10 ≥10 ≥10
(%)
Leakage Points (points/m2) No
High Temperature Anti-Oxidization Performance(180℃/h) No Oxidization
Width Tolerance (+2.0,-2.0)






3oz Conductive Shielding Tape 1320mm Wider Electrodeposited 0
