Customized Design I131 Hot Cell Perfect Solution for Nuclear Safety

Product Description:

JVVMED-DUHCS75-RFM adopts a complete isolation protection design and features a clean arc stainless steel inner cavity, which fully meets the requirements for positron radiopharmography synthesis. The high standards of lead shielding and biological cleanliness are essential not only to comply with radiation safety environmental standards but also to ensure a cGMP clean pharmaceutical environment during the synthesis of positron radiopharmoneuticals.

The hot chamber consists of three main parts:

• The control area is situated in the upper section of the hot chamber and includes an independent ventilation system, hot chamber control unit, gas valve, and radiation dose monitoring and interlocking unit.
• The working area is located in the middle part of the hot chamber, and access for the operator is through opening the front shield door. The spacious internal design is capable of accommodating all synthesizers available on the market.
• The auxiliary area is positioned at the lower part of the hot chamber, ensuring it can fulfill the auxiliary function requirements of the hot chamber.

Features:

• Product Name: Nuclear Radiation Protection
• Type: Hot Cell
• Protection level: 10Pbmm 20mmPB 50Pb 100Pb
• Features: Nuclear Safety
• Nuclear medicine equipment: Hot Cell, Hot Lab
• Color: Stainless Steel Color

Technical Parameters:

Main Technical Parameters

• cGMP biological cleanliness level working area
• Dual synthetic lead chamber made of stainless steel by seamless welding
• Cleanliness: Class C
• Negative pressure: -50Pa~-200Pa
• Demand air volume: 300 m3/h
• Sealing: Second Level Standard Sealing
• Air supply: high efficiency filter
• Exhaust: activated carbon filter

Lead shielding conforming to ICRP radiation environmental safety standards

• Front side: 75mmPB
• Left/right side: 60mmPB
• Target line shielding: 50mmPB
• The radiation dose at the surface of the hot chamber < 5μSv/h @3Ci-F18
• The radiation dose at 30cm of the hot chamber < 1μSv/h @3Ci-F18

Size

• Internal dimensions: 850 mm (w)*619 mm (d)*700 mm (h)
• External dimensions: 1185 (w)*1117(d)*2400 (h)
• Accessories: lamp, UV lamp, ozone sterilization device, power socket, etc

Applications:

Jovi 1-CF-56 Nuclear Radiation Protection is a cutting-edge product designed to ensure nuclear safety in various application occasions and scenarios. Originating from China, this product boasts a high protection level of 10Pbmm, 20mmPB, 50Pb, and 100Pb, making it ideal for handling Nuclear Medical Radiation with precision and efficiency.

The Jovi 1-CF-56 Hot Cell model is particularly suitable for nuclear medicine equipment such as F18 Hot Cell and I131 Hot Cell. These specialized hot cells provide a secure environment for handling radioactive materials used in medical procedures, ensuring the safety of both personnel and the surrounding environment.

Whether in research laboratories, medical facilities, or industrial settings, the Jovi 1-CF-56 Nuclear Radiation Protection product offers essential shielding capabilities to minimize radiation exposure. The inclusion of Tungsten Radiation Shielding as an accessory further enhances the protective features of this product, making it a reliable choice for professionals working with radioactive materials.

With a minimum order quantity of 1 set and packaging details in a wooden case, the Jovi 1-CF-56 Nuclear Radiation Protection product guarantees safe transportation and storage. Customers can expect a prompt delivery time of 25 working days after payment, with convenient payment terms of T/T in advance for added convenience.

In summary, the Jovi 1-CF-56 Nuclear Radiation Protection product is a versatile solution for a range of applications requiring stringent nuclear safety measures. Its specialized design, high protection level, and compatibility with Hot Cell and Hot Lab equipment make it an essential tool for professionals working in the field of nuclear medicine and radiation protection.
