Emi Shielding Conductive Sponge Fabric Gasket Foam For Rf Door Emi Cabinet

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Name | Emi Shielding Conductive Fabric Gasket Foam For RF Door EMI Cabinet | Material | Conductive Fabric, Foam, Conductive Adhesive |
---|---|---|---|
Application | RF Shielded Door Box Cabinet | Length | 500 Pcs |
Feature | With Adhesive | Shape | Customized Shape |
Charactieristic | High Shielding Performance | Color | Silver |
Highlight | emi shielding conductive sponge,emi cabinet conductive sponge |
Emi Shielding Conductive Fabric Gasket Foam For RF Door EMI Cabinet
Product Name: Conductive Foams
Product Performance:
Surface Resistive: ≤ 0.05Ω/ inch(100 gload)
EMI Effectiveness: 60dB- 80dB/ 30MHz- 1GHz( ASTM4935)
Heat Resistance Temperature: - 10℃ - 110℃
Adhesion Strength: ≥ 1. 3( kg/ 25mm)
Initial Adhesion: 1600g/ 25mm( Non- conductive type)
Keep Adhesion: 1440min/ inch
Product Composition:
Density: 50kg/ m3
Elongation: 75%
Fire Rating Grade: UL94( HF- 1)
Product Information:
product name | Gold plated EMI Gasket | Ripstop Fabric over Foam Gasket | Anti-Tarnish EMIGasket | Aluminium Foil EMI Gasket | |||||
items/spe | jv-701 | spe | jv-707 | spe | jv-703 | spe | jv-702 | spe | |
surface resistance(Ω/inch) | 0.05 | Gold has excellent conductive and electrochemical performance. This is a premium EMI Gasket and it is suitable for a large base of materials and applications | 0.05 | Woven fabric is used as the base material which is plated with layers of nickel, copper, and then nickel | 0.05 | In Order to prevent tarnishing,corrosion resistance,and fingerprints Anti-Tarnish treatments have been done on all Products.The application results in a thin surface memberance which allows the product to keep the same resistance and color. | 0.05 | Aluminium Foil Gasket are flexible and combine with Fiberglas which provides the same shielding capacities and performance of metal , including heat application .It is a low-cost substitute for traditional conductive foam and fabric. | |
Frequency Range(Test)(10MHz-1Ghz)(dB) | >85 | >85 | >85 | >85 | |||||
Density(/inch) | 290±10 | 260±10 | 260±10 | ||||||
Weight (g/㎡) | 95±10 | 80±10 | 80±5 | 47±3 | |||||
Breaking Strength(MPa) | warp | 81±10 | 42±10 | 40±10 | 32±10 | ||||
weft | 92±10 | 37±10 | 40±10 | ||||||
Elongation(%) | warp | 21±3 | 17±3 | 22±3 | 40±10 | ||||
weft | 28±3 | 15±3 | 22±3 | ||||||
Dimdension Range(mm) | width:1.8-60 thickness:0.5-50 deformation band(%):20-75 compressive force(kg/m):20-30 residual deformation(%):<15 gap filling range(mm):0.5-37.5 |
Our Services:
1. Delivery within 10 working days after receiving payments.
2. Offer Different Shipping Ways to our customers.
3. Track the order until you get the products
4. As usual, the seaport we used is in Tianjin, Shenzhen...
5. Shaped in roll or sheet, and packed in a wooden case.
6. we can offer free samples for our customers from all over the world.
7. we will replace the broken parts.
8. We can provide you with the Trade Assurance service on Alibaba, online business through Alibaba is safer.
9. You can choose the kinds of trade terms: FOB/ CIF/ CFR/ EXW...
10: We can offer MQO product is 100 pieces
We can offer customized size Conductive Foam product to our customers all over the world.
