45 Cm Backrest Height Fold-and-Go Non-Magnetic Wheelchair Suitable for 3.0T MRI Room Enhancing Transport Efficiency and Safety

The Fold-and-Go Non-Magnetic MRI Wheelchair is designed for rapid deployment and compact storage. The chair folds in two dimensions: the backrest folds forward against the seat, and then the entire chair collapses laterally, reducing its size to 32 inches high, 10 inches wide, and 36 inches deep. The folding mechanism uses nylon hinges with brass pins and requires no tools. The folded chair can be stored in a wall-mounted bracket, under a desk, or in a storage closet. Unfolding takes less than 10 seconds: the user pulls the seat apart laterally, raises the backrest until it clicks, and locks the armrests into place. The chair includes an automatic lock that prevents folding while occupied – a pressure sensor in the seat (non-magnetic, mechanical) disengages the folding mechanism when weight is detected.

This wheelchair is intended for MRI facilities with limited storage space. Many MRI suites are located in areas of hospitals where space is at a premium; storing multiple wheelchairs can be challenging. This chair’s compact folded size allows a facility to keep several chairs on hand without cluttering the hallways. The chair is also useful for mobile MRI units (trailers), where every cubic foot of space matters. The rapid unfolding means that the chair can be kept folded until needed, then deployed in seconds when a patient arrives. The chair is also suitable for home use: patients who need to travel to an outpatient MRI center can keep the folded chair in the trunk of a car, unfold it in the parking lot, and use it to enter the facility.

Frame

aluminum alloy 6061 with brass fasteners

Seat width

18 inches when unfolded

Seat depth

16 inches

Backrest height

16 inches

Folding mechanism

lateral collapse – two seat halves pivot on a central hinge; backrest folds forward on two separate hinges

Hinges

nylon with brass pins, rated for 10,000 folding cycles

Automatic lock

mechanical pressure sensor in seat – a spring-loaded plunger that extends when seat is unweighted, preventing folding when weight is present. Lock can be manually overridden for cleaning or repair

Armrests

flip-back, removable

Footrests

swing-away, removable

Rear wheels

22 inches, composite (smaller than standard to reduce folded size)

Front casters

5 inches, swivel

Brakes

push-to-lock on rear wheels

Weight capacity

300 pounds

Weight of chair

30 pounds

Folded dimensions

32 inches high x 10 inches wide x 36 inches deep

Unfolded dimensions

36 inches high (backrest) x 24 inches wide (armrests) x 32 inches deep

Included accessories

wall-mount bracket for storage (screws into wall studs, non-magnetic aluminum); carrying case with shoulder strap for transport when folded

Warranty

Three-year on folding mechanism; five-year on frame
